Ceyear 2438CB Microwave Power Meter (2CH; 9kHz～500GHz)
Manufacturer: Ceyear Model: 2438CB - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Main unit:
Channels: Double
Frequency range: 9kHz～500GHz
Pulse power range: ——
CW power range: -70dBm～+50dBm
Max. display resolution: Log：0.001dB; Line：0.0001
Relative offset range: ±100.00dB
Rise time: ——
Video bandwidth: ——
Maximum pulse repetition rate: ——
Minimum pulse width: ——
Time base range: ——
Internal trigger level range: ——
Calibration source frequency: 50MHz±1MHz
Calibration source power: 1.000mW（1±1.0%）
Connector type: Type-N（f）
Meter uncertainty: ±1.0%
Display: 4.3 inch colorful LCD
Power requirement: 90～240VAC，50/60Hz, 50Watts Max.
Dimensions (W×H×D): 220 mm * 89 mm * 340 mm
Weight: ≤5kg
Operating/storage temperature: 0℃～50℃/-40℃～+70℃
* Depending on power sensors
See more detail information in the Datasheet
