Coilcraft SER8052-802MEC Power Inductor 8uH Shld 20% 6.31A 14.33mOhms
Manufacturer: Coilcraft Model: SER8052-802MEC - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Width: 8.5 mm
Height: 5.2 mm
Length: 8.8 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 8 uH
Application: High Current
Termination: Standard
Unit Weight: 1 g
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 6.31 A
Saturation Current: 3.86 A
Maximum DC Resistance: 14.33 mOhms
Self Resonant Frequency: 43 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
