Cometech RX-20 Push Pull Gauge (200N)

Measuring range: 200N (20kgf)

Min. display unit: 0.1N

Measurement unit: 3 units (N/kgf/lb) selectable

Measurement item: Peak value, Track value

Accuracy: ±0.2%F.S.

Sampling frequency: 50ms (16ms, 5ms, 1.25ms) selectable Remark:

Display update interval: 1, 2, 5, 10, 20 times / sec, changeable

Display: 6-digit LCD, 44mm×44mm

A/D converter: 16-bit, 100kHz

CPU in use: 16-bit , single-chip CPU

Analog output: ±2V/F.S. ※

Communication output: RS232C 38400bps

Continuous run time: Approx. 12 hours

Applicable temperature range: 0 to 40℃

Dimension: W68×H232×D40mm

Weight: Approx. 450g

Power supply: Ni-Cd battery, AC power adaptor
