Cosel PCA1000F-12-P3 Switching Supplies AC/DC PS (Enclosed Type) 1000W, 12V, 88A Master/Slave Operation
Manufacturer: Cosel Model: PCA1000F-12-P3 - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Width: 102 mm
Height: 41 mm
Length: 178 mm
Industry: Medical
Approvals: ANSI/AAMI ES60601-1, cUL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1
Compliance: ANSI/AAMI ES60601-1, C-UL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1
Efficiency: 91 %
Unit Weight: 1.2 kg
Output Power: 1.056 kW
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 45 Hz to 66 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 88 A
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
