EEC 7472 High Withstand Voltage Tester
Manufacturer: EEC Model: 7472 Guarantee: 12 Month - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
MODEL THAY THẾ: Associated Research HypotMAX 7710
INPUT
• Voltage (AC): 115/230V ± 15% Auto Range
• Frequency: 50/60 Hz ± 5%
DC WITHSTAND VOLTAGE
• Output Rating: 12kV/10mA
• Output Voltage Range: 0-12kV
• Voltage Resolution: 10V
• Voltage Accuracy: ±(1.5% of setting + 10V)
• Current Measurement Range: 0-9999μA
• Current Resolution: 0.1/1μA
• Current Accuracy: ±(2% of reading + 3 counts)
GENERAL
• Interface: Standard: USB & RS232, Optional: GPIB
• Display: 20 x 2 LCD with back light
• Dimension (W x H x D), mm: 430 x 133 x 400
• Weight: 24kg
