Evikon E2618-PID Solvent Vapors Transmitter (0~200 ppm)
Manufacturer: Evikon Model: E2618-PID - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Detected vapors: acetone, ethanol, toluene, xylene etc
Default calibration: isobutylene
Sensor type: Photo Ionization Detector
Sampling method: Diffusion
Detection range: 0...40 ppm isobutylene
0...200 ppm isobutylene
Resolution: 0.01 ppm C4H8 for 40 ppm range
1 ppm C4H8 for 200 ppm range
Sensor lifetime: 5 years
Power supply: 12...36 VDC (default), 24 VAC or 230 VAC as options
Digital interface: RS485, Modbus RTU protocol
Analog outputs: 2 × 4-20 mA / 0-10 V, user settable
Enclosure: grey ABS plastic, wall mount, IP65
Dimensions: H82 × W80 × D55 mm
Operating conditions: -40...+65 °C, < 95 %RH
