FROMM P358 Pneumatic Powered Plastic Strapping Tool (16/0.65-1.05/4.0)

Characteristics

Strapping qualities: Polyester (PET) & Polypropylene (PP), plain and embossed

Strapping dimensions: width 16.0 - 19.0 mm/5/8-3/4"; thickness 0.65 - 1.35 mm / .026-.053"

Weight : 5.7 kg / 12.6 lbs

Tool size:  L350 x W133 x H135,5 mm / 13.78" x 5.2" x 5.3"

Type of seal: Sealless, friction weld sealing

Average seal strength: approx. 75% (depending on strap quality)

Tension force: 1.000 -2.300 N/225-517 lbs | 1.900 – 4.000 N / 427 - 900 lbs (adjustable)

Tension speed:  approx. 115 mm/s -41⁄2"/s | 70 mm/s -2 3/4"/s. See chart of types.

Max. air pressure: 5,5-6,0 bar / 80 - 87 psi

Air consumption: 100 NI/min - 3.5 cu.ft/min Max. pressure drop of 0,5 bar / 7.25 psi

Suspension bracket:  supplied with the tool

Chart of types

Widths: 16.0mm; 5/8 inch

Thicknesses:  0.65-1.05mm; .026 - .041 inch

Max tension: 4000N; 900 lbs

Tension speed: 70 mm/s; 2.7inch/s
