GLOBAL 1405 100W Triple Output Switching Power Supply (1.0 – 36 VDC; 0.25 – 3 A)
Manufacturer: Global Specialties Model: 1405 - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Input Voltage (Universal input): 100–240 VAC, 50/60 Hz
Full Load Input Current at 230 VAC: 0.83 A
Output Voltage Adjustable Range: 1.0 – 36 VDC
Output Current Adjustable Range: 0.25 – 3 A
Voltage Regulation:
+ Load from 10% to 90% Variation: 70 mV
+ Line from 90 to 264 VAC Variation: 25 mV
+ Ripple & Noise (peak to peak): ≤150 mV
Current Regulation:
+ Load from 10% to 90% Variation: 50 mA
+ Line from 90 to 264 VAC Variation: 20 mA
+ Ripple & Noise (peak to peak): ≤50 mA
Switching Operation Frequency: 50 kHz to 150 kHz
Aux Output 1: Fixed 3.3 /5 VDC. 1.8 mA cont. 2 A Max.
Aux Output 2: Fixed 12 VDC, 800 mA cont. 1 A Max.
Power Factor: >0.9
Efficiency at Maximum Power: ≥80.5%
Dimensions (WxHxD): 70 x 150 x 250 mm (2.8 x 6.0 x 9.8 in)
Weight: 2 kg (4.4 lbs)
