Hammond Manufacturing 158S DC Filter Choke DC reactor, filter choke, open channel mount, inductance 1.5H, DC current 250 ma.
Manufacturer: Hammond Manufacturing Model: 158S - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Width: 50.8 mm
Height: 71.374 mm
Length: 82.55 mm
Shielding: Unshielded
Tolerance: 15 %
Inductance: 1.5 H
Application: DC Filtering
Termination: Standard
Unit Weight: 680.388 g
Mounting Style: Chassis Mount
Termination Style: Wire Leads
Maximum DC Current: 250 mA
Maximum DC Resistance: 60 Ohms
