SPECIFICTIONS
- Measurement Modes: LCR, Transformer testing (N, M, ΔL), Continuous testing (LCR mode)
- Measurement Parameters: Z, Y, θ, Rs (ESR), Rp, DCR (DC resistance), X, G, B, Cs, Cp, Ls, Lp, D (tanδ), Q, N, M, ΔL, T
- Measurement Range: 100 kHz to 120 MHz
- Basic accuracy: Z : ±0.05%rdg. θ: ±0.03°
- Output impedance: 100 Ω, Low impedance high accuracy mode: 25 Ω
- Measurement signal level:
+[Normal mode]
_ V mode, CV mode: 5 mV to 5 Vrms, 1 mVrms steps
_ CC mode: 10 μA to 50 mArms, 10 μArms steps
+[Low impedance high accuracy mode]
_ V mode, CV mode: 5 mV to 2.5 Vrms, 1 mVrms step
_ CC mode: 10 μA to 100 mArms, 10 μArms steps
- Measurement Time: 2 ms (1 kHz, FAST, display OFF, representative value)
- Functions:
DC bias measurement, DC resistance temperature compensation
(converted reference temperature display), Comparator, BIN
measurement (classify function), Panel loading/saving, Memory function
- Interface: EXT I/O (Handler), USB communication (high-speed), USB memory
Optional: Choose 1 from RS-232C, GP-IB, or LAN
- Power supply: 100 to 240 VAC, 50/60 Hz, 50 VA
- Dimensions, mass: 330 mm (12.99 in) W × 119 mm (4.69 in) H × 168 mm (6.61 in) D, 3.1 kg (109.3 oz)
- Supplied accessories: Power cord ×1, Instruction Manual ×1, CD-R (Includes PC commands and sample software) ×1
- The warranty period: 12 month
| IM3533 | IM3533-01 | |
| Measurement modes | LCR, Transformer testing (N, M, ΔL), Continuous testing (LCR mode) | LCR, Transformer testing (N, M, ΔL), Analyzer (sweep testing), Continuous Testing (LCR/ Analyzer mode) |
| Measurement parameters | Z, Y, θ, Rs (ESR), Rp, DCR (DC resistance), X, G, B, Cs, Cp, Ls, Lp, D (tanδ), Q, N, M, ΔL, T | |
| Measurement range | 100mΩ to 100MΩ, 10 ranges (All parameters defined in terms of Z ) | |
| Displayable range | Z, Y, Rs, Rp, Rdc, X, G, B, Ls, Lp, Cs, Cp : ± (0.000000 [unit] to 9.999999G [unit]) Real value display for Z and Y only θ: ± (0.000° to 999.999°), D: ± (0.000000 to 9.999999) Q: ± (0.00 to 99999.99), Δ%: ± (0.0000% to 999.9999%) |
|
| Basic accuracy | Z : ±0.05%rdg. θ: ±0.03° | |
| Measurement frequency | 1mHz to 200kHz (1mHz to 10Hz steps) | |
| Measurement signal level | [Normal mode] V mode, CV mode: 5 mV to 5 Vrms, 1 mVrms steps CC mode: 10 μA to 50 mArms, 10 μArms steps [Low impedance high accuracy mode] V mode, CV mode: 5 mV to 2.5 Vrms, 1 mVrms step CC mode: 10 μA to 100 mArms, 10 μArms steps |
|
| Output impedance | Normal mode: 100 Ω, Low impedance high accuracy mode: 25 Ω | |
| Display | 5.7-inch touch-screen color TFT, display can be set to ON/OFF | |
| Measurement time | 2 ms (1 kHz, FAST, display OFF, representative value) | |
| Functions | DC bias measurement, DC resistance temperature compensation (converted reference temperature display), Comparator, BIN measurement (classify function), Panel loading/saving, Memory function |
|
| Interface | EXT I/O (Handler), USB communication (high-speed), USB memory Optional: Choose 1 from RS-232C, GP-IB, or LAN |
|
| Power supply | 100 to 240 V AC, 50/60 Hz, 50 VA max | |
| Dimensions, mass | 330 mm (12.99 in) W × 119 mm (4.69 in) H × 168 mm (6.61 in) D, 3.1 kg (109.3 oz) | |
| Supplied accessories | Power cord ×1, Instruction Manual ×1, CD-R (Includes PC commands and sample software) ×1 | |
