JPT YDFLP-CL-200-5-A Mopa Fiber Laser (>200W/ 5mJ/ 1-4000kHz)
Manufacturer: JPT Model: YDFLP-CL-200-5-A - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Application
Laser paint stripping
Metal surface processing, Peeling coating
Laser derusting
Pre-welding treatment
Sheet metal welding
Hand-held marking
Specification
M²: <4
Armored Cable Length (m): 5
Nominal Average Output Power (W): >200
Maximum Pulse Energy (mJ): 5
Pulse Repetition Rate Range (kHz): 1 ~ 4000
Pulse Duration (ns): 2 ~ 500
Output Power Stability (%): <5
Cooling Method: Air Cooled
Supply DC Voltage (VDC) (V): 48
Maximum Power Consumption (W): <800
Environmental Supply Current (A): >16
Central Emission Wavelength (nm): 1064
Emission Bandwidth @3dB (nm): <15
Polarization Orientation: Random
Anti-high Reflection: Yes
Output Beam Diameter (mm): 6.5±1.0
Output Power Tuning Range (%): 0 ~ 100
Operation Temperature (℃): 0 ~ 40
Storage Temperature (℃): -10 ~ 60
Net Weight: 30 kg
Size(L×W×H): 523 x 430 x 133 mm
JPT CL series laser make use of master oscillator power amplifier (MOPA) configuration,and show excellent laser performance as well as high level of temporal pulse shaping controllability. As compared to the Q-switching technology, the pulse repetition frequency (PRF) and pulse width can be controlled independently in MOPA configuration, through adjusting different combination of the above parameters, the peak power of laser can be well maintained. And enable JPT laser suitable for more material processing which Q-switch limited. CL series laser designed with ultra-light output connector, and still be anti-high reflection, definitely be the best option for handheld or robot cleaning system.
