KASAHARA TP-30 Integrated fluoroscopy sensor (DC6V)
Manufacturer: KASAHARA Model: TP-30 - Request a Quotation
- Request a Quotation
- Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best priceHanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Measurement method: Sensor Immersion Measurement
Measuring principle: Lens Focused Transmitted Light Measurement
Measurement wavelength: Near-infrared light 880nm
Measuring range: 2．0～200cm
Indication: LCD 3 digits
Minimum resolution: 0．1cm（2．0～99．9cm); 1cm （100～200cm）
Reproducibility: ± 3% (FS) or less (under certain conditions)
Calibration:
(1) Simple calibration filter (2) Equivalent standard solution for calibration
Measured water temperature: 2℃～40℃
Ambient temperature: 0°C~40°C, humidity 95%RH or less
Power supply voltage: Alkaline batteries DC6V (AA 5×4pcs), auto power-off function
Material: POM, Rubber
External dimensions: 48×32×320（mm）
Weight: Approx. 300g
Standard Configurations: Fluorosis sensor, anti-impact rubber cover, dry battery, case, measuring container (PVC), instruction manual, simple calibration filter
