Kason Q-80Z Manual and Automatic Metallographic Specimen Cutting Machine (2200 rpm)
Manufacturer: Kason Model: Q-80Z - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Cutting Chamber Housing: Steel Sheet
The Maximum Cutting Diameter: 80mm (Pipe)
The Effective Length Of The Workpiece: 200mm
Cutting Table Size: 290*300mm
Cutting Sheet Specifications: 250*2.5*32mm
Clamping Table Size: Jig Table Left And Right, Center Cutting Edge
Cutting Mode: Manual And Automatic
Reset Mode: Manual Reset
Cooling System: 2 kênh làm mát bằng nước
Water Tank Capacity: 65 L
Spindle Speed: 2200 r / min
Motor Power: 2.2 KW
Dimensions: 950 * 700 * 600mm
Power Supply: 380V, 50Hz
Weight: 220 KG
