KEITHLEY 2460 SourceMeter SMU Instrument (105V, 7A, 100W)

Max. Output Power 100 W, four-quadrant source or sink operation.
Source Limits Vsource: ±7.35 V (≤7 A range), ±10.5 V (≤5 A range), ±21 V (≤4 A range), ±105 V (≤1 A range).
Isource: ±7.35 A (≤7 V range), ±5.25 mA (≤10 V range), ±4.2 A (≤20 V range), ±1.05 mA (≤100 V range).
Overrange 105% of range, source and measure.
Regulation Voltage: Line: 0.01% of range. Load: 0.01% of range + 100 µV.
Current: Line: 0.01% of range. Load: 0.01% of range + 100 pA.
Source Limits Voltage Source Current Limit: Bipolar current limit set with single value. Min. 10% of range.
Current Source Voltage Limit: Bipolar voltage limit set with single value. Min. 10% of range.
V-Limit / I-Limit Accuracy Add 0.3% of setting and ±0.02% of reading to base specification.
Overshoot Voltage Source: <0.1% typical (full scale step, resistive load, 20 V range, 10 mA I-Limit.
Current Source: <0.1% typical (1 mA step, RLoad = 10 kΩ, 20 V range).
Range Change Overshoot Overshoot into a fully resistive 100 kΩ load, 10 Hz to 20 MHz BW, adjacent ranges: <250 mv="" typical="" br=""> Output Settling Time Time required to reach 0.1% of final value, 20 V range, 100 mA I-Limit: <200 s="" typical="" br=""> Maximum Slew Rate 1 V per µs, 100 V range, 100 mA limit into a 20 kΩ load (typical). 0.6 V per µs, 20 V range, 100 mA limit into
a 20 kΩ load (typical).
Over Voltage Protection User selectable values, 5% ±0.5 V tolerance. Factory default = none.
Voltage Source Noise 10Hz–20MHz (RMS): <4.5 mv="" typical="" into="" a="" resistive="" load="" br=""> Common Mode Voltage 250V DC.
Common Mode Isolation >1G Ω, <1000 pf="" br=""> With handle and bumpers: 106mm high × 255mm wide × 425mm deep (4.18 in ×
10.05 in × 16.75 in).
With bumpers and handle: 4.75 kg
