Leadfluid BT100S Basic Variable-Speed Peristaltic Pump (0.07～330mL/min, 4 CH)

Manufacturer: Leadfluid
Model: BT100S
P/N: BT100S(DT15-44)
Origin: China
Guarantee: 12 Month
Contact
- Request a Quotation
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price

Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636

Dong Nai: 0932.160.940

Specifications
Manufacturer Info

Specifications

Flow range: 0.07～330mL/min

Speed range: 0.1-150 rpm

Speed accuracy: 0.2%

Speed resolution: 0.1-100 rpm, 0.1 rpm resolution; 100-150 rpm, 1 rpm resolution

Power supply: AC 100-240V, 50Hz/60Hz

Power consumption: < 40W

External logic level control signal: 5V, 12V (standard), 24V (optional)

External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)

External communication interface: MODBUS RS485

Ambient temperature: 0-40 °C

Relative humidity: < 80%

IP grade: IP31

Dimension (L x W x H): 264 x 150 x 270 mm (10.39 x 5.91 x 10.63 inch)

Weight: 0.8 kg (1.8 lbs)

Details

Drive type	Pump head	Ch	Tubing size (mm)	Flow rate per channel (mL/min)
BT100S	DG6-1 (6rollers)	1	Wall:0.8-1, ID:≤3.17	0.0002-49
	DG10-1 (10rollers)	1	Wall:0.8-1, ID:≤3.17	0.0001-41
	DG6-2 (6rollers)	2	Wall:0.8-1, ID:≤3.17	0.0001-49
	DG10-2 (10rollers)	2	Wall:0.8-1, ID:≤3.17	0.0001-41
	DG6-4 (6rollers)	4	Wall:0.8-1, ID:≤3.17	0.0002-49
	DG10-4 (10rollers)	4	Wall:0.8-1, ID:≤3.17	0.0001-41
	DT10-18	1	13# 14# , Wall: 0.8-1, ID:≤3.17	0.0002-82
	DT10-28	2	13# 14# , Wall: 0.8-1, ID:≤3.17	0.0002-82
	DT10-48	4	13# 14# , Wall: 0.8-1, ID:≤3.17	0.0002-82
	YZ15	1	13# 14# 16# 19# 25# 17#18#	0.006-570
	YZ25	1	15# 24#	0.16-420
	2 x YZ15	2	13# 14# 16# 19# 25# 17#18#	0.006-570
	2 x YZ25	2	15# 24#	0.16-420
	YT15	1	13# 14# 16# 19# 25# 17#18#	0.006-570
	YT25	1	15# 24# 35# 36#	0.17-720
	2 x YT15	2	13# 14# 16# 19# 25# 17#18#	0.006-570
	2 x YT25	2	15# 24# 35# 36#	0.17-720
