Mark-10 M5-10 Advanced Digital Force Gauges (10 lbF / 160 ozF / 5 kgF / 5000 gF / 50 N)

Capacity x Resolution: Force gauge, 10 lbF / 160 ozF / 5 kgF / 5000 gF / 50 N

Accuracy: ±0.1% of full scale

Sampling Rate: 7.000 Hz

Power: AC adapter: 100-240VAC, 50-60 Hz, 0.3 A

Battery: Rechargeable 8.4V NiMH

Low battery indicator appears when battery level is low, and gauge powers off automatically when power reaches critical stage

Battery life: Backlight on / off: up to 7 / 24 hours of continuous use

Outputs:

USB / RS-232: Configurable up to 115.200 baud. Includes Gauge Control Language 2 for full computer control

Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.

Analog: ±1 VDC, ±2% of full scale at capacity

General purpose: Three open drain outputs, one input

Set points: Three open drain lines

Configurable settings: Digital filters, outputs, automatic output (via USB/RS-232), automatic shutoff, default settings, averaging mode, external trigger, passwords, key tones, audio alarms, backlight, calibration

Safe overload: 200% of full scale (display shows “OVER” at 110% and above)

Weight (lb [kg]): 1.0 [0.45]

Load cell deflection: 0.010 [0.25]

Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensating
