MEAN WELL QP-320D Switching Supplies 5V20A 12V10A 24V3A -12V2A 316W
Manufacturer: MEAN WELL Model: QP-320D - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Width: 115 mm
Height: 50 mm
Length: 215 mm
Industry: Industrial
Approvals: EN60950-1, UL60950-1
Compliance: EN60950-1, UL60950-1
Unit Weight: 1.2 kg
Output Power: 316 W
Input Voltage: 90 VAC to 264 VAC, 127 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Number of Outputs: 4 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 20 A
Output Current-Channel 2: 10 A
Output Current-Channel 3: 3 A
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 12 VDC
Output Voltage-Channel 3: 24 VDC
