Mecmesin FMT-W40C5 Motorised Pull Tester (500 x 0.5 N)

Capacity (f.s.)/ Resolution

500 x 0.5 N / 110 x 0.1 lbf / 50 x 0.05 kgf

Accuracy: ± 0.5% of full-scale (f.s.)
Acquisition Rate: 1000 times per second

Max operating force: 120% of f.s. (auto-reverses to release load if limit exceeded)

Pull speed settings: 10, 25, 37.5, 50, 100, 150 and 200 mm/min

Display: LCD 5 digits, 14mm high

Memory: 1000 readings with max, min, mean and standard deviation calculations

Output: via USB 2.0 Interface

Dimensions mm (LxWxH): 320 x 160 x 115

Supplied with:

  • Standard: Pull Tester fitted with Crimp Receptacle and Cable Cam fixtures, USB interface cable, CD-ROM with software (trial version - no licence), power supply.

  •  Optional: Operating instructions with CE declaration of conformity(printed), Dakks (German) calibration certificate, software licence, interchangeable adapter and carrying case  - order separately as required.
