Memmert UF160TS Pass-through oven (161L)

  • Manufacturer: MEMMERT
    Model: UF160TS
    Origin: Germany
    Guarantee: 12 month
    • Request a Quotation Request a Quotation
  • 139,104,059 VND
  •  Call for best price

    Hotline: (+84) 867820758

    Phone+84 (24)62923267

  • Quality Engagement
  • Easy change and return
  • Delivery Avaliable
  • Favorable payment

Manufacturer: Memmert- Germany

Model: UF160TS

Origin: Germany

Warrant: 12 months


- Volume: 161 liters

- Interior dimensions: 560W x 720H x 400D mm

- Exterior dimensions: 745W x 1233H x 582D mm

- Stainless steel grids (standard): 2

- Max. number of grids: 8

- Max. loading per grids: 20 kg

- Max. loading of chamber: 210 kg

- Working temperature range: at least 10 above ambient temperature to 2500C

- Setting accuracy: up to 99.90C; 0.10C, from 1000C; 0.50C

- 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error

- ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays.

- Language setting: German, English, Spanish, French, Polish, Czech, Hungarian

- Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days

- Function HeatBALANCE: adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 %

- Function setpointWAIT: the process time dose not start until the set temperature is reached

- Calibration: three freely selectable temperature values

- Fan: forced air circulation by quite air turbine, adjustable in 10 % steps for each segment individually

- Fresh air admixture: adjustment of pre-heated fresh air admixture by air flap control in 10 % steps for each segment individually

- Programme stored in case of power failure

- Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port

- Temperature control: independently working, digitally adjustable electronic micro-processor overtemperature monitor TWW, protection class 3.1 (max-value for overtemperature, min-value for undertemperature), mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature

- AutoSAFETY: additionally integrated over - and undertemperature protection "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature

- Autodiagnostic system: for fault analysis

- Alarm: visual and acoustic

- Displaying of already logged protocol data on the ControlCOCKPIT (max 10,000 values correspond to approx. 1 week)

- Ethernet interface on the rear of the appliance for reading out the protocol log and for uploading programmes and for online logging

- Structured stainless steel housing, scratch-resistant, robust and durable; rear of zinc-plated steel

- Internal data logger with a storage capacity of at least 10 years

- Voltage: 230 V, 50/60 Hz

- Electrical load: approx. 3200 W

- Ambient temperature: 5 – 400C

- Humidity: max. 80% rh, non-condensing

Accessories:

+ Works calibration certificate at 1600C (Memmert supply)

+ Stainless steel grid, 2 pc

+ Manual
