OMEGA SV3106 2-Way, NC, Direct Acting, Brass, Solenoid Valves (0.1 gal/min, 1/4 in, BSPP Male, 1/16 in, Direct Acting, Normally Closed)

Mounting: Any (preferably with solenoid system upright)

Cv Factor: 0.1 gal/min

Materials: Brass, FKM, Stainless Steel 300, Stainless Steel 400, Copper

Coil Power: 8 W

Duty Cycle: 100%

Media Type: N/A

Valve Type: Direct Acting

Cycling Rate: 1000 cpm

Orifice Size: 1/16 in

Valve Position: Normally Closed

Enclosure Ratings: NEMA Type 4

Materials, Wetted: Brass, Copper, FKM, Stainless Steel

Voltage Tolerance: ±10%

Open Response Time: 10 to 20 ms

Close Response Time: 20 to 30 ms

Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water

Coil Molding Material: Black Polyester (Class F): SV8COIL-115AC, SV8COIL-24DC/60HZ , SV8COIL-24AC/50 to 60HZ, SV8COIL-220AC Black Polyamide (Class F): SV8COIL-12DC, SV8COIL-24DC Black Polyphenylensulphide (Class H): SV8COIL-115/60HZ

Operating Pressure Note: AC 430 psi, DC 220 psi

Operating Pressure, Max: 430 psi

Operating Pressure, Min: 0 psi

Process Connection Size: 1/4 in

Process Connection Type: BSPP Male

Process Temperature, Max: 137 °C

Process Temperature, Min: -10 °C
