Samyon SP-5 Video Measuring Apparatus (125 um)

Specifications:

   SP-5 is equipped with digital microscope (with rotary encoder)

   and combined with 40X objective lens:  Resolution: 0.01um

   SP-5 is equipped with manual microscope (without rotary encoder)

   and combined with 40X objective lens:  Resolution: 0.125um

   SP-5 is equipped with manual microscope (without rotary encoder)

   and combined with 1X objective lens:  Resolution: 5um

   Measuring range:  Combined with 40X objective lens: 125 um

                     Combined with 10X objective lens: 500 um

                     Combined with 1X objective lens: 5000 um

   Optical system:

   Total magnification: 400X (measurement)

                                  100X (measurement)

                                  1X (measurement)

   CCD system:

         Horizontal definition: 570 lines

         Display mode: Black and white

         Input voltage: DC12V±10%

   LCD display system:

         Screen size: 8”

         Input voltage: DC12V±10%

   Voltage stabilizer input voltage: 220V, 50Hz

   Power consumption: ≤20W

   Dimensions: φ47×170mm

   Weight: 1 kg


Standard accessories:

   CCD camera

   LCD screen

   Optical part
