Triad Magnetics FS24-1500-C2 Split Bobbin Transformer POWER XFMR 24 Vct a. 1500 mA UL/cUL - Class 2/3, TUV, 115/230V SPLIT PACK PCB MOUNT / FS24-1500-C2
Manufacturer: Triad Magnetics Model: FS24-1500-C2 - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Width: 2.187 in
Height: 1.562 in
Length: 2.625 in
Unit Weight: 498.300 g
Power Rating: 36 VA
Mounting Style: Through Hole
Primary Winding: Dual Primary Winding
Secondary Winding: Dual Secondary Winding
Termination Style: Solder Pin
Operating Frequency: 50 Hz/60 Hz
Primary Voltage Rating: 115 VAC, 230 VAC
Secondary Current Rating: 1.5 A/3 A
Secondary Voltage Rating: 24 V CT/12 V
