Vitrek DL215 Electronic DC Load (0-150V, 21mΩ-700kΩ, 12Vdc, 60VA)

VOLTAGE:

Input Voltage: 0-150V

Voltage Measurement Accuracy: 0.04%+1mV

Voltage (CV) Loading: Full range of voltages, user configurable resistance from 1mΩ upwards

CV Loading Accuracy: 0.04%+1mV

Sense Loading: Nominally 923kΩ, automatically included in all measurement results and all loading except open

CURRENT:

Current (CC) Accuracy: 0.05%+10µA

POWER:

Power (CW) Accuracy: 0.075%+50µW

RESISTANCE:

Resistive Loading: 21mΩ-700kΩ

Resistive (CR) Accuracy: 0.1%

Capacitive Loading: 0.3µF

LOADING MODES and TIMING:

Load Timing: Continuous, or 5µs to 10000s pulsed/stepped

Non-linear Loading Bandwidth: Typically >35kHz with ability to reduce bandwidth

Size: 5 inches high x 8.5 inches wide x 13 inches deep

Weight: Approximately 8 pounds (unpacked, without external power supply)

Power: External 12Vdc, 60VA power brick

Display: 5-inch diagonal, 800x480 pixel color LCD with touchscreenWarm Up Time: 20 seconds

Full Specifications: 15 minutes

Temperature:

Operating: 0 to +40°C, at 10 to 80% RH (non-condensing) Automatically reduces loading if overheating detected.

Storage: -20°C to +70°C, at 5 to 95% RH (non-condensing)
