YOKOGAWA AQ6370D Telecom Optical Spectrum Analyzer (600-1700nm)
Manufacturer: YOKOGAWA Model: AQ6370D Guarantee: 12 Month - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Band: Optical communications
Wavelength range(nm): Min. 600; Max. 1700
Wavelength accuracy (nm): ±0.1 (Full range); ±0.04 (1450 to 1520 nm); ±0.01 (1520 to 1580 nm); ±0.02 (1580 to 1620 nm)
Wavelength linearity (nm): ±0.01 to 0.02
Wavelength resolution setting (nm): Min. 0.02; Max. 2
Maximum number of sampling: 50001
Measurement level range (dBm): Max. +20; Min.−60 (600 to 1000 nm) or−80 (1000 to 1300 nm)or −90 (1300 to 1620 nm)
Level accuracy (dB): ±0.4
Level linearity (dB): ±0.05
Level flatness (dB): ±0.1 to ±0.2
Polarization dependence (dB): ±0.05 to ±0.08
Dynamic range (dB): 50 (±0.1 nm, RES: 0.02 nm); 78 (±1.0 nm, RES: 0.05 nm)
Applicable fiber: SMF, G
Purge feature: No
Built-in cut filter for high order diffracted light: No
Light source for optical alignment: Yes
Light source for wavelength calibration: Yes
