Revalve S-6-600/160 Test Benches For Shut Off & Control Valves

Specifications:

Maximum clamping force: 160 t

Distance between test tables:(″) 66/1506 (2½ / 59) (min/max)mm

Distance between screw rods(″): 1004 (40) mm

Electric power supply: 400/50 V/Hz

Power consumption: 20kW

Overall dimensions (LхWхH)(″):4080х1445х1632(160x57x64)mm

Weight: 3436kg

* Maximum diameter for wedge gate valves (except ball valves).
