Full Scale Range: 1 Torr
Set Point Range: 0.002 - 1 Torr
Sensor Temperature: 100°C
Fitting Type: 0.5 in. OD tube
Accuracy: ±0.5% of range (± temperature coefficients)
Zero Temperature Coefficient: ±0.015% of Full Scale/°C
Span Temperature Coefficient: ±0.03% of set point/°C
Operating Temperature Range: 20 - 70°C
Response Time: <20 msec from 0 to Full Scale
Relay Mode: Energizes above set point
Relay Contact Ratings: DPDT, 2 amps @ 30 VDC or 1 amp @ 120 VAC resistive
Exposed Materials: Inconel and 316 S.S.
Internal Volume: 7.0 cc
Overpressure: 120% of Full Scale or 35 psia (1000 mmHg), whichever is larger
Power Requirements: 20 - 30 VDC, 1.2 A
For specific range please check the attachment below!
