Home Discontinued Products BK Precision 1740B Analog DC Power Supply (0~60V/4A)

BK Precision 1740B Analog DC Power Supply (0~60V/4A)

Output Voltage: 0-60 V
Output Current: 0-4 A
Ripple & Noise: 1mV rms, <3mArms
Metering: 2-Analog
Overload Protection: Current limiting, reverse polarity, overvoltage, short circuit
Power Requirements:  120/220 VAC ±10%, 50/60 Hz
Power Consumption: 450W
Dimension: 145x267x381 mm
Weight: 10.4kg

Details
  • Continuously monitor voltage and current output on two analog meters
  • Connect two supplies in parallel to double the current output
  • Connect two supplies in series to double the voltage output
  • Reliable, Durable
  • Operate continuously at full load without overheating
  • Fully overload protected
  • Coarse and fine voltage controls
  • Excellent regulation
  • Very low ripple
  • Constant voltage or constant current operation



Tags:BK Precision 1740B Analog DC Power Supply (1~60V/4A)
