Bourns PWR220T-35-2000J Power Resistors 200ohm 35W 5% TOL Thru Hole
Manufacturer: Bourns Model: PWR220T-35-2000J - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Width: 4 mm
Height: 14.6 mm
Length: 10.1 mm
Tolerance: 5 %
Resistance: 200 Ohms
Technology: Thick Film
Unit Weight: 4.899 g
Lead Spacing: 5.08 mm
Power Rating: 35 W
Lead Diameter: 0.72 mm
Mounting Style: PCB Mount
Voltage Rating: 2 kV
Termination Style: Radial
Temperature Coefficient: 100 PPM / C
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
