MKS GS100 Industrial Microwave Generators (2450MHz; 10kW)
Manufacturer: MKS Model: GS100 - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Maximum Power Output: 10 kW
Frequency: 2440 - 2470 MHz
Power Regulation: 10 - 100%
Ripple: ±5% of output power, max.
Ambient Temperature: Up to 40°C maximum
Microwave Connections: WR340 waveguide with PDR26 flange
Remote Control: RS232, ANYBUS (optional)
Power Supply: SM 1690
Power Supply Dimensions: 444 x 310 x 482 mm (HxWxD)
Magnetron Head: TM100
Input Power: 3 x 400 V, 50/60 Hz, 3 x 480 V, 50/60 Hz
Waveguide: WR340
Power Head Cooling: Water cooled
Power Supply Cooling: Forced air, approx 200 m3/h
Power Head Dimensions: 375 x 235 x 225 mm (height x width x depth)
Compliance: CE, EN61010-1, EN61000-6-4, EN61000-6-2
