Monolithic Power Systems (MPS) MPQ3326GR-AEC1-P WLED Drivers 16 Channels, 50mA/ch, LED Driver With Separated PWM Analog Dimming and I2C Interface
Manufacturer: Monolithic Power Systems (MPS) Model: MPQ3326GR-AEC1-P - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Dimming: PWM
Features: PWM Dimming, Short Circuit and Thermal Protection
Topology: Boost, Buck
Input Voltage: 4 V to 16 V
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Output Current: 50 mA
Output Voltage: Adjustable
Development Kit: EVQ3326-R-00A
Number of Outputs: 16 Output
Number of Channels: 16 Channel
Input Voltage - Max: 16 V
Input Voltage - Min: 4 V
Operating Frequency: 245 Hz
Supply Current - Max: 4 mA
Pd - Power Dissipation: 2.97 W
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
